| Title | Specifications |
|---|---|
| Size | 0.25 Inch ID0.25 Inch ID |
| SKU | S300601S300601 |
| Input Pressure | 60 psi0.41 MPa |
| Radial Load Max | 2.75 lb12 N |
| Radial Stiffness | 0.01 lb/μin2 N/μm |
| Pitch Moment Max | 0.125 lb-in0.013 N-m |
| Pitch Stiffness | 0.20 lb-in/mil rad0.022 N-m/mil rad |
| Flowrate on Shaft | 2.25 - 3.30 SCFH0.97 - 1.43 NLPM |
| Air Gap at maximum recommended load | 150 micro-inches4 microns |
| Bushing Inside Diameter (ID) | 0.2502 in +.0002/-.00006.355 +0.005/-0.000 mm |
| Bushing Outside Diameter (OD) | 0.6 in15 mm |
| Bushing Length | 1.25 in32 mm |
| Bushing Weight | 0.38 oz11 g |
| Housing Material/Finish | Aluminum/AnodizedAluminum/Anodized |
| Porous Media Material | CarbonCarbon |
| Recommended Shaft Outside Diameter (OD) | 0.2495 in6.337 mm |
| Recommended Shaft Tolerance | -.0002/-.0006 in (g6)-5/-14 μm (g6) |
| Recommended Mounting Bore Diameter | 0.635 in +.005/-.00016.13 mm +.13/-.00 |
| Pressure Port Threads | M3 x 0.5M3 x 0.5 |
| Maximum Allowable Pressure Supply | 100 psi0.689 MPa |
| Bushing ID Speed | 140,000 rpm140,000 rpm |
| Resolution | InfiniteInfinite |
| Maximum Speed | 164.04 ft/s50 m/s |
| Common Shaft Materials | Anodized aluminum, stainless steel, nickel plated steel, ceramics, glassAnodized aluminum, stainless steel, nickel plated steel, ceramics, glass |
