NW-TB-04-01

Introducing the Future of Turbomachinery Bearings: The Externally Pressurized Porous Media Turbomachinery Thrust Bearing Unlock unparalleled performance and reliability with our NW-TB-04-01 Thrust Bearing – the cutting-edge solution redefining the way you approach high-speed machinery. The NW-TB-04-01 is our largest turbomachinery thrust bearing. Designed to meet the most demanding industrial applications with a shaft size of 4 inches, this innovative thrust bearing technology is the key to smoother operations, reduced maintenance, and enhanced productivity. Contact us today to start improving your Turbomachinery Axial Motion!
Category:
Units: US METRIC
Title Specifications
Model # NW-TB-04-01NW-TB-04-01
Shaft Size 4.00 in.101.60 mm
Shaft Flange Thickness .625 in. +.0002/-.000215.88 mm +0.01/-0.01
Maximum Speed 15,000 RPM15,000 RPM
Supply Pressure 60 - 140 PSIG413.7 - 965.3 KPA
Flow Consumption @ 60 PSIG (413.7 KPA) 88 -123 SCFH41.7 - 58.4 SLPM
Stator Bore Requirement 7.515 in. +.002/-.000 190.88 mm +0.05/-0.00
Max. Angular Misalignment 2.5°2.5°
Porous Media Material Carbon GraphiteCarbon Graphite
Housing Material 316 Stainless Steel, FDA Compliant Materials Available316 Stainless Steel, FDA Compliant Materials Available
O-ring Materials Viton 75AViton 75A
